Havells SPN C Curve MCB 32A Single Pole with Neutral DHMXCSNZ032 | 6kA Overload & Short Circuit Protection
Havells SPN C Curve MCB 32A Single Pole with Neutral DHMXCSNZ032 | 6kA Overload & Short Circuit Protection
-36%

Havells SPN C Curve MCB 32A Single Pole with Neutral DHMXCSNZ032 | 6kA Overload & Short Circuit Protection

Rs. 479.00
Rs. 748.00
35% off

Product Specification

  • Sku: DHMXCSNZ032
  • Available: outstock
  • Brand: Havells
  • Rated Voltage: 240V AC / 415V AC
Ask a Question

Hurry Up! Only 0 left in stock!

Notify me when in stock

Estimate delivery times: 3-6 days (International).

Return within 10 days of purchase. Duties & taxes are non-refundable.

Havells SPN C Curve MCB 32A Single Pole with Neutral DHMXCSNZ032 | 6kA Overload & Short Circuit Protection
Havells Store
Havells SPN C Curve MCB 32A Single Pole with Neutral DHMXCSNZ032 | 6kA Overload & Short Circuit Protection
Rs. 479.00
Rs. 748.00
35% off

Havells 32A SPN C Curve MCB

The Havells SPN C Curve MCB is designed for reliable circuit protection in residential, commercial, and light industrial electrical distribution systems. With single pole with neutral execution, 6kA short circuit breaking capacity, flame-retardant thermoplastic material, and C Curve tripping, it helps protect low voltage circuits from overload and short circuit faults, including motor and inductive load applications.

Key Features

  • 32A SPN MCB suitable for low voltage circuit protection.
  • Single pole with neutral execution for phase and neutral circuit applications.
  • C Curve tripping characteristic suitable for motor and inductive load applications.
  • 6kA rated short circuit breaking capacity for dependable fault protection.
  • Flame-retardant thermoplastic material for improved electrical safety.
  • Hammer trip mechanism for reliable tripping performance.
  • Line and load interchangeability for flexible installation.
  • Designed as per IS/IEC 60898-1 standard.

Technical Specifications

Brand Havells
Product Type MCB
SKU DHMXCSNZ032
Current Rating 32A
Type Single Pole with Neutral
Curve C Curve
Rated Frequency 50 Hz
Rated Voltage 240V AC / 415V AC
Rated Insulation Voltage 690V
Rated Impulse Voltage 4kV
Rated Short Circuit Breaking Capacity 6kA
Terminal Capacity 25 mm²
Protection Class IP20
Operating Temperature -5°C to 50°C
Mounting 35 mm x 7.5 mm DIN Rail
Installation Position Vertical / Horizontal
Tightening Torque 2 Nm
Dimensions 84 mm x 60.2 mm x 17.7 mm
Country of Origin India
Net Contents 1 Main Unit

Applications

  • Residential distribution boards
  • Commercial electrical panels
  • Motor and inductive load protection
  • Single pole with neutral circuit protection
  • Overload and short circuit protection in low voltage systems
